Sizes in Stock
Metric Size : M02 to M160
Sizes Can Be
Manufacture
Up to 4"
Steel Type
Nickel Base Alloys
Dimensions
ASME B18.2.1 and ASME B18.3
Length
3mm to 200mm
Grades
UNS N06625, N10276, N05500
Advantages
High Strength with Excellent Toughness
Commonly Used
Airplanes and Marine
Delivery Time and Location
Table Of Content
8 years experience as an ASTM F468 bolts manufacturer in India, buy online ASME F468 UNS N06625 nonferrous bolts available in all sizes, and directly contact ASTM F468 stud bolts stockist and save up to 15 to 18% in Mumbai.
ASTM F468 Specification
Size In Ready Stock
ASTM F468 Bolts
ASTM F468M Threaded Rod
F468 Studs
ASTM F468 Standard
Manufacturing Method
Advantage
Testing Checklist
Available Packaging
Finish
Application
Certificate & Report
Value Added Services
Material Origin
Production Process of ASME F468 UNS N06625 Nonferrous Bolts
| Hot Forging | M24 to M100 |
|---|---|
| Cold Froging | M2 to M24 |
| CNC machining | Custom Size |
Grades Covers by ASTM F468 Bolts
| UNS | Grade |
|---|---|
| ASTM F468 UNS N06625 | Inconel 625 Fasteners |
| ASTM F468 UNS N10276 | Hastelloy C276 Bolts |
| ASTM F468 UNS N04400 | Monel 400 Fasteners |
| ASTM F468 UNS N05500 | Monel K500 Fasteners |
Germany Standard for ASTM F468 UNS N10276 Screws
Heat Condition for F468 Alloy 400 Stud Bolts
| ASTM F468 Material | Condition |
|---|---|
| Inconel 625 Fasteners | Annealed |
| Titanium Fasteners | Formed |
| Monel 400 Fasteners | Formed or Stress relieved |
| Monel K500 Fasteners | Solution annealed |
Recommended Nuts & Washers for F468 UNS N05500 Hex Bolts
Nut
Washer
ASTM F468 Chemical Composition
| General Name | Alloy | UNS Designation | Tin | Lead, max | Zinc, max | Silicon | Phosphorus | Nickel, max | Manganese, max | Iron, max | Copper, min | Aluminum |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Brass Bolts | 270 | UNS C27000 | - | 0.10 | balance | - | - | - | - | 0.07 | 63.0 - 68.5 | - |
| Phosphor Bronze Fasteners | 510 | UNS C51000 | 4.20 - 5.80 | 0.05 | 0.30 | - | 0.03 - 0.35 | - | - | 0.10 | balance | - |
| Aluminum Bronze Fasteners | 613 | UNS C61300 | 0.20 - 0.50 | 0.01 | 0.05 | 0.10 | 0.015 | 0.15 | 0.10 | 2.0 - 3.0 | B | 6.0 - 7.5 |
| Silicon Bronze Fasteners | 651 | UNS C65100 | - | 0.05 | 1.50 | 0.8 - 2.0 | - | - | 0.70 | 0.80 | 96.0 | - |
| Cupro Nickel | 715 | UNS C71500 | - | 0.05 | 1.00 | - | - | 29.0 - 33.0 | 1.00 | 0.40 - 0.70 | 65.0 | - |
| General Name | Alloy | UNS Designation | Vanadium | Sulfur, max | Molybdenum | Cobalt, max | Silicon, max |
|---|---|---|---|---|---|---|---|
| Ni-Mo-Cr | Hastelloy C276 Bolts | UNS N10276 | 0.35 max | 0.030 | 15.0 - 17.0 | 2.50 | 0.08 |
| Ni-Cu Class A | Monel 400 Fasteners | UNS N04400 | - | 0.024 | - | B | 0.50 |
| Ni-Cu-Al | Monel K500 Fasteners | UNS N05500 | - | 0.010 | - | B | 0.50 |
| Phosphorus, max | Manganese, max | Iron, max | Copper | Chromium | Carbon, max | Nickel | Aluminum |
|---|---|---|---|---|---|---|---|
| 0.040 | 1.00 | 4.00 - 7.00 | - | 14.5 - 16.5 | 0.02 | balance | - |
| - | 2.00 | 2.50 | balance | - | 0.30 | 63.0 - 70.0 | - |
| 0.015 | 1.50 | 2.00 | balance | - | 0.25 | 63.0 - 70.0 | 2.30 - 3.15 |
F468M Bolt Thread Length
| ASTM F468 Bolt Length | 2" or less | Over 2" to 6" | Over 6" |
|---|---|---|---|
| ASTM F468 Bolt Thread Length | 2 Threads of the head | 2" min + 2 threads | 3" min + 2 threads |
Types Of ASTM F468 Bolts
ASTM F468 Hex Bolt
ASTM F468M Allen Bolt
ASTM F468 UNS N06625 Hex Head Bolt
ASTM F468 UNS N10276 Stud Bolts
ASTM F468 Alloy 400 Anchor Bolts
F468 Inconel 625 Screw
F468 N10276 Self Tapping Screw
ASTM F468 UNS N05500 Threaded Rod
ASTM F468 UNS C46200 Studs
